Name: Aeronautics Telecommunications Military Circular Connectors Plugging Unplugging
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: Yumurta.0b.307.cll
Price: 12.30 USD
Availability: InStock

B series FGG EGG black chrome wire harness cable automotive circular push pull connector for military device

Parts Description

RAYMO P/N	Lemo P/N
RM-EGG-0BC-302-KS	EGG.0BC.307.CLL

EGG panel socket,7pins,female solder connector, black chrome plated brass
Different shell size from 00B to 4B
Multipoles contacts from 2pins to 32 pins

Main Features

100% compatible with LEMO FGG EGG
security of the Push-Pull self-latching system
multipole types 2 to 32 contacts
solder/ print contacts (straight or elbow)
multiple key options to avoid cross mating,such us 30, 45, 60, 90, 135
high packing density for space savings
5000 times push pull

Technical Characteristics

Temperature Range	- 40° C, +125° C	Resistance to vibrations	15 g [10 Hz - 2000 Hz]
Shell Material	Brass with chrome plated	Humidity	up to 95% at 60° C/140F
Shock Resistance	100 g [ 6 ms]	Salt spray corrosion test	>144hr
Climatical Category	50/175/21	Shielding (min)	> 75 dB [ at 10 MHz], > 40 dB [ at 1 GHz]
IP Rating	IP50	Endurance(shell)	5000 mating cycles

Company Intrce

SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented circular push pull connector and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers

With professional R&D and excellent craftsmanship, our factory has the ability of offering customer with much more precision connectors and cable harness solution to meet customer's real needs in his field.

Application

Medical LIKE Therapy applications
Test & measurement LIKE Automation
Transport LIKE Automotive
Defense & Security LIKE Computers
Broadcast LIKE High Speed Camera
Energy LIKE TV and motion picture
Extreme LIKE Nuclear

Pictures of EGG socket

Aeronautics Telecommunications Military Circular Connectors Plugging Unplugging 0

Contacts ans shell size

Shell size	Contacts no. ( Both with Solder & PCB type )
Shell size	Contacts no. ( Both with Solder & PCB type )
RM-00	2	3	4
RM-0B	2	3	4	5	6	7	9
RM-1B	2	3	4	5	6	7	8	10	12	14	16
RM-2B	2	3	4	5	6	7	8	10	12	14	16	19
RM-3B	3	4	6	8/(6+2)	9(8+1)	10	12	14(13+1)	14	16	18	21	26	30	32
RM-4B	7	10	24

Advantages

Sample Free:1-2 PCS
Fast lead time: 3-5 work days if the QTY is under 200 PCS
Flexiblity payment way:T/T,PayPal,Westunion,Credit card
24 hours service for clients
Competitive price & stable prction
Certified CE and RoHS
OEM/ODM/Cable Assemble
World-class customer service

RFQ

1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular connectors and cable assembly since 2010.Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 9 years.
2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample :
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5. What is your payment terms?
Raymo: 100% T/T deposit when customer place order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory
has instruments to tested them before shipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!

Etiket:

Menşe yeri:	Shenzhen, Çin
Marka adı:	RAYMO
Sertifika:	ISO:9001-2015, CE ,RoHS2.0, SGS, REACH
Model numarası:	Yumurta.0b.307.cll

Min sipariş miktarı:	5 adet/adet
Fiyat:	negotiable
Ambalaj bilgileri:	Plastik Torba ve Karton
Teslim süresi:	5-7wds
Ödeme koşulları:	Western Union, L/C, D/A, D/P, T/T
Yetenek temini:	5000 Adet / Hafta

Seri:	Yumurta dairesel itme çekme konnektörü	Cinsiyet:	Kadın temasları
İletişim Numarası.:	2,3,4,5,6,7,9pin	yalıtkan:	PPS/PEEK
Dayanıklılık:	5000 kez itme çekme	başvuru:	İletişim
Vurgulamak:	mil spec wire connectors , military plugs connectors
