LEMO Redel Series Plastic Push Pull Connector Cable Plug Automotive Industrial Grade

LEMO Redel Series Plastic Push Pull Connector Cable Plug Automotive Industrial Grade
LEMO Redel Series Plastic Push Pull Connector Cable Plug Automotive Industrial Grade LEMO Redel Series Plastic Push Pull Connector Cable Plug Automotive Industrial Grade LEMO Redel Series Plastic Push Pull Connector Cable Plug Automotive Industrial Grade
Temel bilgi
Menşe yeri: Shenzhen, Çin
Marka adı: RAYMO
Sertifika: CE ROHS ISO SGS
Model numarası: Pag.m0.2glac39g
Min sipariş miktarı: 1 Parça/Parça
Fiyat: negotiable
Ambalaj bilgileri: Plastik Torba ve Karton
Teslim süresi: 3-5 iş günü
Ödeme koşulları: Western Union, T/T, MoneyGram
Yetenek temini: 5000 Adet / Hafta
Şimdi başvurun
PRCT Adı: Plastik dairesel itme-pull konektörü Model: Kablo montaj fişi
Kabuk boyutu: 1P PAG Fişi İletişim Numarası.: 2, 3, 4, 5, 6, 7, 8, 9, 10, 12, 14pins
başvuru: Tıbbi, otomatik Cinsiyet: erkek kadın
yalıtkan: PPS, Peek Kabuk malzemesi: PC, PSU, Peek
IP Sıralaması: IP50 Ömür boyu: ≥1000 kez
Vurgulamak:

plastic push pull connector

,

raymo connectors

Prct Description

Raymo plastic circular push pull  connectors RM-P series

Part No.Good Description
RM-PAG-1PC-302JS39G

Plastic circular push pull cable mount connector, PAG cable plug, 2pin male contact, 39 cable collet for OD1.0-3.9mm cable, round nut , one key, 0 degree, gray colour shell, gray colour cap



Raymo high quality plastic connectors are found that can be widely  used  in below applications:


Medical, Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application.

SHENZHEN RAYMO ELECTRONICS TECHNOLOGY LIMITED is a manufacturer located in Shenzhen, focusing on manufacturing Creative customer-oriented metal and plastic circular push-pull self-latching connectors and cable assemblies to serve over 75 countries and regions since 2010. Our prcts got very popular recommendation among our customers ​



Below is the shell size and contact RAYMO have for plastic circular connector :



Plastic Circular Push Pull connector RM-p series
SeriesIPShell SizeContacts No. with solder & PCB type
RM-P401P /Redel234567891012

14




Main Feature
Secure Push-pull Self-locking system
High density assembly to save space.
Alignment Key and Polarized Keying System to avoid cross-interface.
Colorful plug round nut and socket screw nut for choice, easy for identify
Available solder and PCB or right angle PCB contact.




Technical Characteristics
Temperature Range- 40° C, +150° CResistance to vibrations15 g [10 Hz - 2000 Hz]
Shock Resistance100 g [ 6 ms]Salt spray corrosion test>96hr
Climatical Category50/175/21Shielding (min)

> 75 dB [ at 10 MHz]
> 40 dB [ at 1 GHz]

IP RatingIP 40Certifications

ISO9001 CE ROHS2.0 SGS





RM-P PAG Cable Plug Prcts Photo, Shell size and Dimension

LEMO Redel Series Plastic Push Pull Connector Cable Plug Automotive Industrial Grade 0



FAQ


1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing Circular Connectors and cable assembly since 2010.Our factory is SGS audited manufacturer and worked on www.alibaba.com more than 9 years.
2.  What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample ?
Raymo: Available. Any needs, please contact us.
4.  What about the lead time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5.  What is your payment terms?
Raymo: 100% T/T prepayment when customer place order .
6.  Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory has instruments to tested them before shipping. Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty
