5pin Ip68 Circular Waterproof Connector Plug Socket 0k FGG EGG M14 Cable Connectors

Description FGG.0K.305.CLAD52Z

5poles, male solder contacts
IP68 Circular Waterproof connector
PPS insulator
100% compatible with Original Lemo connector
Natural in chrome palted brass

Features

Size/Series	0K (Metal (Mechanical Keying))
Shell Style/Model	Straight plug,cable collet
Keying	1 key (alpha=0, plug: male contacts, receptacle: female contacts)
Housing Material	Brass (chrome plated) shell and collet nut, nickel plated brass latch sleeve and mid pieces
Configuration	Brass (gold plated)
Insulator	PPS
Contact Type	Solder
Endurance (Shell)	5000 mating cycles
Temp (min)	-40 deg
Temp (max)	220 deg C
Humidity (max)	<=95% [at 60 deg C / 140 F]
Vibration	15 g [10 Hz - 2000 Hz]
Shock Resistance	100 g [ 6 ms]
Salt Spray Corrosion	>144 hr
IP Rating	68

Shell size and contacts for option

Shell size	Contacts no. ( Both with Solder & PCB type )
Shell size	Contacts no. ( Both with Solder & PCB type )
RM-0K	2	3	4	5	6	7	9
RM-1K	2	3	4	5	6	7	8	10	12	14	16
RM-2K	2	3	4	5	6	7	8	10	12	14	16	19
RM-3K	3	4	6	8/(6+2)	9(8+1)	10	12	14(13+1)	14	16	18	21	26	30	32
RM-4K	7	10	24

Application

Medical LIKE Diagnostic devices
Test & measurement LIKE Sensors
Transport LIKE Maritime
Defense & Security LIKE Target acquisition
Broadcast LIKE Studios and outside broadcasting
Energy LIKE Remote camera control
Extreme LIKE Nuclear

Raymo Company information

RAYMO is a manufactuer that:

Focus on manufacturing & exporting various metal & plastic circular push pull connectors, cable assembly.
Can be 100% compatible with original LEMO • •FISCHER• HIROSE • BINDER •Military 38999
Series has RM-B, RM-K, RM-S, RM-F,RM-E,RM-HR10A, RM-P, RM-M4, RM-M12, RM-M16, BNC, B680,B423 , 38999, 26482
CO, Form A, Form E for customer clearance
CE, ROHS, REACH, ISO:90001-2015, SGS Audited manufacturer

RM-K Series FGG Shell type dimension and pictures

5 Pin IP68 Electrical Plug Connector 0K FGG EGG M14 Chrome Palted Brass Black Shell 0

Advantages

Sample Free:1-2 PCS
Fast lead time: 3-5 work days if the QTY is under 200 PCS
Flexiblity payment way:T/T,PayPal,Westunion,Credit card
24 hours service for clients
Competitive price & stable prction
Certified TUV CE and RoHS
OEM/ODM/Cable Assemble
World-class customer service

Why you need buy Raymo's compatible connector?

Help you save at least 50% cost
100% compatible lemo connector
Cable assembly offer,help you save prction time
Large stock,short lead time and easy to buy
We can provide OEM/ODM service and cable assembly solution
it has excellent compatibility with many leading supplier
our company has over 9 years experience and strong professional research and development capabilities.Advanced development and management, comprehensice R&D TESTING and highly automatic prction line make our prcts high reliablilyty and high performance.
Our comapny has passed ISO90001,and got CE, REACH, RoHS and SGS certification

FAQ

1. Are your company a professional manufacturer?
Raymo: Yes, we SGS audited manufacturer
2. What is the MOQ?
Raymo: No MOQ limited, depend on customer real needs.
3. Free sample?
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: 3-5 working days for samples, 5-7 working days for mass prction.
5.What is your payment terms?
Raymo: 100% T/T in advance when customer place an order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating, our factory has instruments to tested them before shipping. Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!

Etiket:

Menşe yeri:	Shenzhen, Çin
Marka adı:	RAYMO
Sertifika:	CE, RoHS2.0, SGS, REACH, ISO9001:2015
Model numarası:	FGG.0K.305.Clad42Z

Min sipariş miktarı:	1 Parça/Parça
Fiyat:	negotiable
Ambalaj bilgileri:	Plastik Torba ve Karton
Teslim süresi:	5-7 iş günü
Ödeme koşulları:	Western Union, L/C, D/A, D/P, T/T, MoneyGram
Yetenek temini:	Haftada 5000 parça

Tip:	Dairesel Push Çekme Su geçirmez konektör	Pinler:	2, 3, 4, 5, 6, 7, 9 pin
Kabuk boyutu:	0K, diğer kabuk boyutu mevcuttur	yalıtkan:	PPS, Peek de mevcuttur
Yaşam döngüsü:	5000 kez itme çekme	Kablo assle:	Evet, müşteri gerçek ihtiyaçlarına göre
Vurgulamak:	outdoor electrical connector , waterproof dc connector
