Name: S SSC Chrome Plated Brass Waterproof Circular Connector IP68
Brand: Shenzhen Raymo Electronics Technology Limited
SKU: S 103 A053 140
Price: 8.99 USD
Availability: InStock

S SSC Chrome Plated Brass Waterproof Circular Connector IP68

Temel bilgi

Menşe yeri:	Shenzhen, Çin
Marka adı:	RAYMO
Sertifika:	CE/ ISO9000:2015/ ROHS/ SGS/ REACH
Model numarası:	S 103 A053 140

Min sipariş miktarı:	5 parça/parça
Fiyat:	negotiable
Ambalaj bilgileri:	Plastik Torba ve Karton
Teslim süresi:	5-7wds
Ödeme koşulları:	Western Union, L/C, D/A, D/P, T/T
Yetenek temini:	5000 Adet / Hafta

Şimdi başvurun

Kabuk modeli:

S Kablo Monte Konektörü IP68

Tip:

Fischer su geçirmez konektör

Kabuk boyutu:

0F/102

İletişim Numarası.:

2 pim ila 16 pim

Bağlantı türü:

PPS/PEEK İSOLATÖRÜ İLE LADIN KONUŞULARI

başvuru:

Otomotiv

Vurgulamak:

S SSC Waterproof Circular Connector

Chrome Plated Waterproof Circular Connector

IP68 Brass Power Connector

Shenzhen RAYMO is a manufacturer that:

♣ Manufacturing & exporting various metal & plastic circular connectors and cable assembly

♣ All prcts can be 100% compatible with original LEMO • FISCHER • • HIROSE • BINDERS and Military 38999

♣ Cable Assembly can be designed according customer real needs

♣ All the prcts we got CE, ROHS, SGS,ISO9000 certificate

♣ OEM connector and Cable assembly

• All the items can work normally after 5000 times mating

We can make all types of cables and connectors as per customers' request. Use any kind of connectors, like Hirose, Cannon, BNC, TNC, D-sub, USB, RJ45, Dtap, JST, Molex, and so on. Just tell us your need, leave the rest to RAYMO

S SSC natural chrome plated brass waterproof circular connector for automotive

Parts No.:RM-S-1F1S-P04JS50= S 103 A053 140+

103/1F contacts: 2 pin 3 pin 4 pin 5 pin 6 pin 7 pin 8 pin 10 pin 12 pin 14 pin 16 pin

Description
1	100% substitute with original Fischer
2	IP68 circular cable connector,4 pins, male solder contacts with black shell
3	different shell size is available from 102,103,1031 and 104
4	Sealed to IP68 and Hermetic
5	360° EMC shield
6	Available Solder,PCB or right angle PCB contacts
7	Robust and shock resistant designs

Technical Characteristics
Temperature Range	- 65° C, +200° C	Resistance to vibrations	15 g [10 Hz - 2000 Hz]
Shock Resistance	100 g [ 6 ms]	Salt spray corrosion test	>96hr
Climatical Category	50/175/21	Shielding (min)	> 75 dB [ at 10 MHz] > 40 dB [ at 1 GHz]
IP Rating	IP 68	Certifications	ISO9001 CE ROHS2.0 SGS

S SSC Chrome Plated Brass Waterproof Circular Connector IP68 0

RAYMO's high quality connectors are found in a variety of challenging applications and environments including:
Automotive, Audio-video, Aviation, Communications, Industrial Control, Information Systems, and Machines, Medical, Military, Test and Measurement, Data Acquisition, Data Transfer Equipment. Mle Power, Sensor,Sensor Systems Instrumentation, Analysis Application

Why choose us:

100% compatible Fischer connector
Help you save at least 50% cost
Cable assembly offer,help you save prction time
Fast lead timei s 5-7 working days

Exhibition

2020.9	Testing Expo Shanghai
2019 9.24-9.26	Testing Expo, Shanghai
2018 11.12-11.15	Electronica Munich, Germany
2017 9.11-9.16	NAB Show,Netherlands
2016 4.11-4.15	HK Fair
2015 10.2-10.7	ICEEB, Brasil
2014 10.11-10.15	HK Fair
2014 4.11-4.15	HK Fair

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
