Silicone Sealing IP68 Waterproof Cable Connector Compressive Strength

Part No.:

PHG.2K.319.CLLD52Z/ RM-PHG-2KC-319KS52Z

Prct Description:

2K size connector, PHG cable mount socket, 19pin female contact, 52 cable collet, nut for a bend relief, natural chrome plated shell in brass

Main Futures

1

Waterproof Secure high performance push-pull Self-locking system

2

100% compatible with original Lemo K series connector

3

can plated with white or black chrome

4

2-32pin available

5

Available solder and PCB or right angle PCB contact.

6

360° EMC shield

7

Certificate:ISO:9001-2015, CE ,RoHS2.0, SGS, Reach

Technical Characteristics

Temperature Range

- 65° C, +200° C

Resistance to vibrations

15 g [10 Hz - 2000 Hz]

Shell Material

Brass with chrome plated

Humidity

up to 95% at 60° C/140F

Shock Resistance

100 g [ 6 ms]

Salt spray corrosion test

>144hr

Climatical Category

55/175/21

Shielding (min)

> 95dB [ at 10 MHz],     > 80 dB [ at 1 GHz]

IP Rating

IP 68

Endurance(shell)

≥5000 mating cycles

Shell size

Contacts no. ( Both with Solder & PCB type )

0K

2

3

4

5

6

7

9

1K

2

3

4

5

6

7

8

10

12

14

16

2K

2

3

4

5

6

7

8

10

12

14

16

19

3K

3

4

6

8

9

10

12

14

14

16

18

21

26

30

32
